A very compact base and rover configuration The FGS 1 contains a very efficient digital data link. The 3G technology also allows extending the measuring baseline over 100 kilometers. This allows the user to work with a single receiver in the field eliminating the logistical burden of setting up a base station in the field. Network rover configuration The FGS 1 Network rover relies on its 3G field computer to communicate with GNSS networks via a cellular network or the internet.
Can i use my gcx2 with field genius serial#
TECHNICAL DATA Signal Tracking 256 channels with simultaneously tracked satellite signals: GPS L1 C/A, L1/L2P, L5 GLONASS L1/L2 BeiDou B1, B2, B3 Galileo Yes, but not activated SBAS WAAS, EGNOS, MSAS Performance Specifications Cold start 99,9% Signal reacquisition <2s 2 TECHNICAL DATA Positioning Specifications Post processing static horizontal 2,5 mm + 0,5 ppm RMS vertical 5,0 mm + 0,5 ppm RMS Real time kinematic horizontal 10 mm + 0,5 ppm RMS vertical 20 mm + 0,5 ppm RMS E-RTK (<100km) horizontal 0,20 m + 1 ppm RMS vertical 0,40 m + 1 ppm RMS Code differential GNSS positioning horizontal 0,25 m + 1 ppm RMS vertical 0,50 m + 1 ppm RMS SBAS typically <1 m 3D RMS Stand-alone <1,5 m RMS Communication 1 Serial port (7 Pin Lemo), Baud rates up to 921 600 bps Radio modem (optional) Tx/Rx with full frequency rang from 410 4702 MHz transmit power 0.5 2W adjustable Positioning update rate 1 Hz, 2 Hz, 5 Hz, 10 Hz 5 LED Indicating lights Power, satellite tracking, differential data and data recording Bluetooth V 2.X protocol, work compatible with Windows 7, Windows mobile and Android Data Format Data inputs / outputs Correction data I/O RTCM 2.x, 3.x, CMR & CMR+ (GPS only) Position data outputs ASCII NMEA-0183 GSV, RMC, HDT, VHD, GGA, GSA, ZDA, VTG, GST, PJK, PTNL geo-fennel Binary update to 20 Hz Key features High speed processing Support for both post-processing and kinematic Processing ability separate or to be combined with GPS, GLONASS and BeiDou Supports downloads & use of precise ephemeris Generation of various reports User friendly 3 The system is open to third party applications and supported by MicroSurvey FieldGenius and Carlson Surv-CE field applications. The smart design positions the FGS 1 among the lightest and most compact receivers currently available.
The FGS 1 integrates a cutting edge GNSS board, Bluetooth, optional UHF (Rx & Tx) into a compact system. The strong anti-interference ability of the receiver makes it possible to work in any environment. By using a unique algorithm it can operate in RTK mode combining all GNSS constellation signals or by using a single GNSS constellation signal such as GLONASS or BeiDou. The FGS 1 can track all current working GNSS constellations. FGS 1 Unique GPS Set for multipurpose applications The geo-fennel FGS 1 is a robust receiver designed for challenging environments integrated into a compact device that is lightweight and highly portable.
